Troubleshooting Guide

Troubleshooting Guide

Most VelocityNavigator problems come from a server name that differs between files, a backend that cannot be reached from the proxy, or a feature that is enabled without all of its required settings. Start with these two commands:

/vn config validate
/vn health

The first checks configuration; the second shows what the running proxy can currently see.

Players cannot reach a lobby

Check the following in order:

1. The lobby exists in Velocity's velocity.toml.
2. The same name appears in routing.default_lobbies or the relevant contextual group.
3. The proxy can reach the backend address and port.
4. /vn health does not show it as offline, drained, full, in lifecycle-disallowed state, in maintenance, or blocked by its circuit breaker.
5. A finite max_players has not already been reached.
6. With geo routing enabled, the lobby's configured country affinity includes the player's resolved country.

Names are case-insensitive in most routing paths, but keeping the same spelling everywhere makes mistakes easier to spot.

Initial joins still prefer the first Velocity server

Confirm that initial routing is enabled:

[routing]
balance_initial_join = true

Then make sure every expected lobby is registered and included in the routing pool. Velocity's try order remains the fallback when the plugin cannot produce an eligible initial target. If authentication is enabled, the configured holding lobby short-circuits the initial route for unverified players. See Initial Join Balancing for the full setup.

Distribution looks uneven

Small samples look uneven, especially with random or power_of_two. Use /vn status after a meaningful number of joins to review the recorded distribution.

Also check:

• least_players and power_of_two react to current load instead of enforcing an exact rotation;
• weighted routing sends more players to higher-weight lobbies;
• player affinity may return recent players to the same healthy lobby;
• different max_players values change the available capacity;
• geo_distance prefers lobbies in the same country as the player;
• maintenance or drain state may be removing servers you expected to receive traffic.

If you need a strict, visible rotation while checking the setup, use round_robin.

A healthy server is being skipped

A successful ping is only one eligibility check. The server may also be:

• in drain mode;
• at its configured capacity;
• held out by an open circuit breaker;
• outside the player's contextual routing group;
• advertising a backend state that is not allowed;
• flagged for maintenance through Maintenance Mode;
• excluded by the geo-distance selection matcher.

Use /vn servers for the per-lobby view and /vn health for the subsystem summary. The Health Checks and Circuit Breakers, Backend Lifecycle States, and Maintenance Mode pages explain those controls.

The circuit breaker keeps opening

Repeated health or connection failures open the circuit. Check the backend console, firewall, address, port, and proxy-to-backend latency before increasing thresholds.

For planned maintenance, use /vn drain <server> or /vn maintenance <server> on <reason>. Both prevent new routes without treating the backend as an unexpected failure.

Configuration changes do not apply

Run /vn reload, then read the result in chat or the proxy console. A failed reload keeps the last usable configuration.

Common causes include:

• invalid TOML punctuation or quoting;
• an unknown routing mode;
• duplicate command names;
• an invalid port or negative feature limit;
• a referenced server that is not registered with Velocity;
• a missing holding server ID for authentication;
• a missing GeoLite2 database file at the configured path;
• conflicting storage.toml and [storage] block values when both are present.

Do not edit active_language in messages.toml; change language and let the plugin update the active value.

Commands are missing or denied

Check that the command has not been renamed in navigator.toml, and confirm the player has the configured permission. A permission value of none allows everyone.

Party and queue commands disappear when their feature is disabled. Run /vn config validate after changing command names because the lobby, admin, party, party-chat, and queue commands must not collide.

The Java inventory selector falls back to chat

The Java inventory is rendered by the Paper/Spigot/Folia backend bridge. Put the same universal JAR on every backend where the menu should open, restart that backend, join it once, and run:

/vn bridge status

If the bridge is absent or its handshake cannot complete, chat fallback is expected. Check that plugin messaging is allowed and that the proxy and backend use the same VelocityNavigator version. See Java and Bedrock Selectors.

The Bedrock form does not open

Confirm Geyser and Floodgate are installed and that Bedrock support and the form are enabled. If automatic detection is unreliable in your proxy setup, review the Floodgate configuration and UUID mapping.

With fallback_to_chat = true, a player still receives a usable chat selector when a native form cannot be shown.

A language did not switch

For a built-in language, change only the top-level value in messages.toml and run /vn reload:

language = "de"

For a custom pack, confirm that plugins/velocitynavigator/languages/<language>.properties exists and the filename matches the configured code. Test with one obvious message such as party.not_in_party, then run /party status.

Keep placeholders such as <server>, <reason>, and {players} intact. Unknown keys are ignored and missing custom keys fall back to English. See Language Packs for a complete example.

A GUI item is missing or in the wrong slot

Check gui.toml for a duplicated slot, a slot outside the configured inventory size, or a material name that does not exist on your backend version. Run /vn config validate, then use a simple material such as PAPER while narrowing down the problem.

Parties do not follow the leader

Confirm party.enabled and party.follow_leader are both true. Members must be online on the same Velocity proxy as the leader. Redis does not make party membership global across proxies.

Use /party status to confirm membership before the leader changes server. If /party accept reports "you are already in a party" when the player expected to join, the previous pending invitation was overwritten; send a fresh /party invite and try again. See Party System.

The queue never starts

Queueing begins only when every eligible lobby is full. Every candidate therefore needs a positive max_players; an uncapped lobby means the pool is never full.

For players joining the proxy while full, holding_server must name a registered Velocity backend that is not itself part of a lobby pool. See Capacity Queue.

Storage backend errors

Confirm [storage] type matches the configured driver (file, sqlite, mysql, mariadb, postgresql). HikariCP pool errors indicate an unreachable JDBC URL or wrong credentials; each database provider creates its tables during initialization. See Storage and Databases.

Redis will not connect

Run:

/vn redis test
/vn redis status

Check the host, port, ACL username, password, TLS setting, and firewall. Each proxy needs a unique persistent node_id. The built-in client expects a standalone Redis-compatible endpoint; Sentinel and Cluster discovery are not supported.

If backend registration is rejected, compare the shared registration secret, advertised host, host allowlist, and system clock on both machines. See Redis and Multi-Proxy.

A managed server change fails

Try the same operation with /vn server dry-run .... Existing server names are protected while allow_overwrite = false, and invalid addresses or forced-host references may require attention.

VelocityNavigator keeps timestamped backups in plugins/velocitynavigator/backups/. See Server Management before changing a live server table.

The dashboard does not open

Check dashboard.enabled, dashboard.port, and dashboard.bind_host. The dashboard and Prometheus exporter cannot use the same port.

127.0.0.1 is universal loopback and accepts connections only from the proxy machine; it is not a personal or public IP. For remote access, bind to a private interface, set a strong bearer token, and restrict the port with a firewall or reverse proxy. Pterodactyl and other hosting-panel users must allocate a separate dashboard port, put that exact number in dashboard.port, and normally use 0.0.0.0 inside the container. See HTML Dashboard.

Prometheus cannot bind

An "address already in use" error means another process has the configured port. Choose a free port, or another allocation supplied by your provider. "Cannot assign requested address" means the selected IP is not attached to that host or container; do not paste the provider's public IP into bind_host unless its documentation requires it.

For local scraping, use 127.0.0.1. For a container or remote scraper, use an appropriate private bind address, bearer token, and firewall rule. The Prometheus and Grafana Setup page includes a ready configuration and dashboard import flow.

Geo routing shows no affinity

First check the active provider in geo.toml or [geo_routing]. For georestrict, confirm GeoRestrict is installed on Velocity and look for GeoRestrict detected during startup. For maxmind, confirm the configured database file exists and is not empty. For ip_api, check outbound HTTP access and rate limits.

When no country is resolved, routing falls back according to the geo fallback settings instead of rejecting the player. Enable verbose logging temporarily to see the country, reason, and candidate list.

Still stuck?

Collect these before asking for help:

• VelocityNavigator version and Java version;
• Velocity version and backend server software;
• the output of /vn config validate and /vn health;
• the relevant proxy log lines;
• sanitized config sections with passwords and bearer tokens removed.

Support is available through DemonZ Development on Discord.
