Quick Start Guide

Quick Start Guide

This guide gets two lobbies working first. Leave menus, authentication, Redis, and geo routing disabled until this basic route works.

Before you start, have these ready:

• one Velocity proxy;
• two backend servers already added to Velocity's velocity.toml;
• the exact Velocity server names for those backends;
• console access, because /vn is an administrator command.

This guide uses lobby-1 and lobby-2. Replace those names everywhere if your servers are called something else.

Step 1: Download and Install

1. Download VelocityNavigator-4.5.0.jar from the VelocityNavigator Modrinth page.
2. Place the JAR in your Velocity proxy's plugins/ folder.
3. Start or restart the proxy. /vn reload reloads configuration; it cannot replace a running JAR.
4. For now, install the JAR only on Velocity. Add it to Paper/Spigot/Folia later if you want inventory menus or NPCs.

plugins/
├── VelocityNavigator-4.5.0.jar
└── ...

On first start, look for:

VelocityNavigator universal JAR is running in VELOCITY PROXY mode.

The proxy creates plugins/velocitynavigator/ with navigator.toml, messages.toml, gui.toml, and the optional feature files.

---

Step 2: Match Your Velocity Server Names

Open Velocity's velocity.toml and find the [servers] table:

[servers]
lobby-1 = "127.0.0.1:25566"
lobby-2 = "127.0.0.1:25567"

The names on the left—lobby-1 and lobby-2—are the names VelocityNavigator needs. Do not put IP addresses in default_lobbies.

---

Step 3: Edit navigator.toml

Open plugins/velocitynavigator/navigator.toml and set your lobby server names:

[routing]
selection_mode = "least_players"
default_lobbies = ["lobby-1", "lobby-2", "lobby-3"]

Important: server names in default_lobbies must exactly match the server names defined in velocity.toml.

Save the file, then run /vn reload in the proxy console.

Now run:

/vn config validate
/vn health

Fix validation errors before testing with players. Both lobby names should appear in the health output.

To change the server-wide language, edit only the language line at the top of messages.toml:

language = "ru"

Built-ins: en, ru, es, fr, de, pt_br, zh_cn, ja, it, ko, nl, pl, tr, ar, hi. Any other value creates a custom-language workflow and preserves text for manual editing. Locale detection is disabled.

Do not enable the inventory selector until normal /lobby routing works. When you are ready:

[routing]
use_menu_for_lobby = true

[routing.java_menu]
type = "inventory"
fallback_to_chat = true

Install the same universal JAR on each lobby backend that should provide Java inventory, NPCs, YAML menus, or backend placeholders. Restart those backends, let a player visit each one, and check /vn bridge status. If a bridge is missing, the Java selector falls back to chat when fallback_to_chat = true; backend NPCs and YAML menus simply cannot run there.

Before enabling advanced systems, run /vn config validate. For managed servers, use /vn server dry-run game ... or /vn server dry-run lobby ... before the real add command.

---

Step 4: Choose a Selection Mode

Follow this decision tree to choose an algorithm:

How many lobby servers do you have?
│
├─ 1–3 servers ──── least_players   (simple, always picks emptiest)
│
├─ 4–10 servers ─── power_of_two    (fast, near-optimal distribution)
│
├─ 10+ servers ──── least_connections (EMA-based, handles bursty traffic)
│
└─ Need sticky sessions?
   │
   ├─ Yes ──── consistent_hash  (players return to "their" server)
   │
   └─ Need weighted distribution?
      │
      └─ Yes ──── weighted_round_robin  (some servers get more traffic)

Mode	Summary
least_players	Picks the server with the fewest players. Suited to small networks.
power_of_two	Picks two at random and chooses the emptier one. Good default for medium networks.
round_robin	Strict rotation. Useful for testing.
random	Each player gets a random server. Performs well at scale.
weighted_round_robin	Round-robin where some servers receive more traffic than others.
least_connections	Tracks connection rate over time. Good for bursty traffic.
consistent_hash	Same player maps to the same server. Useful for session affinity.
latency	Selects the healthy candidate with the lowest measured ping. Useful when latency differs meaningfully between backends.

See Routing Algorithms for the full reference.

---

Step 5: Confirm the Setup

1. Join through Velocity, not directly through a backend port.
2. Type /lobby.
3. Confirm that you reach one of the configured lobbies.
4. Join with a second test player or switch loads, then run /lobby again.

Check the routing decision:

/vn debug player YourName

Verify distribution across your servers:

/vn status

If it does not work, run /vn config validate, /vn health, and /vn servers in that order. The Troubleshooting Guide explains each failure state.

---

Next Steps

• Configuration Guide: customize every setting
• Routing Algorithms: how each algorithm works
• Operations Runbook: drain servers, check health, troubleshoot

---

At this point the basic router is ready. Add one optional system at a time and validate after each change.

v4.5 adds: database storage backends, GeoIP-based routing, maintenance mode, and authentication integration.

Optional advanced systems

VelocityNavigator 4.5.0 provides native parties, full-pool queues, Redis multi-proxy synchronization, dynamic backend registration, MOTD lifecycle-state routing, database storage backends, GeoIP-based routing, maintenance mode, and authentication integration. Configure them using the Advanced Proxy Systems guide.
