📋 DSB Mobile API – Home Assistant Integration

Custom Home Assistant integration for DSB Mobile – the German school substitution plan system used by many schools in Germany.

---

✨ Features

Sensor	Description	Icon
Vertretungsplan	Per-student substitution plan with merged timetable	🏫
Schulinfo	Daily school announcements and metadata	📋
Raw Sensor	All raw DSB data for debugging (optional)	📊

Core Features

• 🧒 Child name & class in setup flow – determines entity IDs and sensor naming
• 📅 YAML timetable support – provide a custom timetable file for schedule merging
• 🔄 Manual fetch – data is fetched on demand via dsb_api.fetch_updates service
• 🔃 Live schedule reload – reload timetable YAML via dsb_api.reload_schedule without restarting HA
• 🏷️ Smart sensor naming – entity IDs follow sensor.dsb_[child]_[class]_vertretungsplan pattern
• 👨‍👩‍👧‍👦 Multi-child support – add the integration multiple times, one per child
• 🔐 Secure authentication – DSB Mobile API credentials validated at setup
• 📏 Recorder-safe – raw debug sensor disabled by default to avoid large attributes
• 🔑 Persistent hash storage – change detection hashes stored per child for automation use

Schedule Merging

When a YAML timetable is provided, the integration merges the regular timetable with DSB substitution data. Each lesson gets a status:

Status	Meaning
normal	No changes – regular lesson
vertretung	Substitution teacher or room change
entfall	Lesson cancelled
verlegung	Lesson moved from/to another slot
raum_aenderung	Room changed
betreuung	Supervised study period

The timetable supports split classes (e.g. two language groups, religion/ethics groups, or gender-separated sports) through an exclude list that filters out lessons not relevant to the specific student [1].

---

📦 Installation

HACS (Recommended)

1. Open HACS in Home Assistant
2. Click ⋮ (top right) → Custom repositories
3. Add https://github.com/workFLOw42/DSB_Mobile_Api as Integration
4. Search for DSB Mobile API and install
5. Restart Home Assistant

Manual Installation

1. Download the latest release
2. Copy the custom_components/dsb_api folder to your config/custom_components/ directory
3. Restart Home Assistant

---

⚙️ Configuration

Initial Setup (3 Steps)

Step 1 – Credentials:

1. Go to Settings → Devices & Services → Add Integration
2. Search for DSB Mobile API
3. Enter your DSB Mobile credentials:

Field	Description	Example
Username	School ID for DSB Mobile	12345
Password	Password for DSB Mobile	••••••••

Step 2 – Child / Student:

4. Enter a name or short code and the class:

Field	Description	Example
Child name	Short code for the student	MAX
Class	Class name as shown in DSB	7B

This determines entity IDs and the default timetable filename:

Input	Entity ID	Schedule File
MAX + 7B	sensor.dsb_max_7b_vertretungsplan	MAX_Stundenplan.yaml
LISA + 5A	sensor.dsb_lisa_5a_vertretungsplan	LISA_Stundenplan.yaml

⚠️ Entity IDs are set during initial setup and cannot be changed later.

Step 3 – Schedule Settings:

5. Optionally provide a timetable YAML file (must be in your HA config directory)
6. Optionally enable the Raw Debug Sensor

Multiple Children

Add the integration once per child:

1. Settings → Devices & Services → Add Integration → DSB Mobile API
2. Use the same credentials but a different child name and class
3. Each child gets its own set of sensors with unique entity IDs

Options

1. Go to Settings → Devices & Services
2. Find DSB Mobile API and click Configure
3. Change child name, class, schedule file, or raw sensor toggle

---

📅 Timetable YAML

The integration can load a custom YAML timetable from your HA config directory. This enables merging the regular timetable with DSB substitution data.

Basic Structure

meta:
  schueler: "MAX"
  klasse: "7B"
  jahrgangsstufe: 7
  schule: "myschool"

exclude:
  - fach: "L2"           # Student takes French, not Latin
  - fach: "K"            # Student has Ethics, not Catholic Religion
  - fach: "Ev"           # Student has Ethics, not Evangelical Religion
  - fach: "Sw"           # Student has male sports (Sm)
  - fach: "E1"
    lehrer: "SMI"        # Student is in the other English group

stundenplan:
  montag:
    "1": { fach: E1, raum: "108", lehrer: MUL, uhrzeit: "08:00-08:45" }
    "2": { fach: E1, raum: "108", lehrer: MUL, uhrzeit: "08:45-09:30" }
    # ...
  dienstag:
    # ...

Extended Structure (for automation integration)

The YAML can include additional blocks used by calendar sync automations:

zeitraum:
  start: "2026-02-04"
  ende: "2026-07-31"

sensoren:
  schulaufgaben: "sensor.myschool_max_schulaufgaben"
  termine: "sensor.myschool_max_termine"
  vertretungsplan: "sensor.dsb_max_7b_vertretungsplan"

ogts:
  betreuung: "Jane Doe"
  montag:     { start: "13:05", ende: "16:00" }
  donnerstag: { start: "13:05", ende: "16:00" }

termine_filter:
  include_keywords:
    - "7."
    - "7B"
    - "Unterstufe"
  exclude_keywords:
    - "Q12"
    - "Q13"
    - "Abitur"
  ferien_keyword: "ferien"
  feiertag_keywords:
    - "unterrichtsfrei"
    - "Buß- und Bettag"
    - "Christi Himmelfahrt"

emojis:
  schulaufgabe: "✒️"
  ogts: "📝"
  schultermin: "🏫"
  ferien: "🏖️"
  feiertag: "🎇"
  kurzstunden: "🌞"
  vertretung: "☢️"
  entfall: "👻"

Exclude Rules

Schools often split classes into groups for languages, religion/ethics, or sports. The exclude list filters out lessons that don't apply to the specific student [1]:

Example	Reason
fach: "L2"	Student takes French, not Latin
fach: "K"	Student has Ethics, not Catholic Religion
fach: "Sw"	Student has male sports
fach: "E1", lehrer: "SMI"	Student is in the other English group

Reload Without Restart

After editing the YAML, reload it without restarting HA:

service: dsb_api.reload_schedule

---

🔄 Fetching Data

This integration uses manual fetch only (no automatic polling). To fetch data:

Via Service Call

service: dsb_api.fetch_updates

Via Automation

automation:
  - alias: "Fetch DSB data every 15 minutes on school mornings"
    trigger:
      - platform: time_pattern
        minutes: /15
    condition:
      - condition: time
        after: "06:45:00"
        before: "14:00:00"
      - condition: state
        entity_id: input_boolean.ferien_status_heute
        state: "off"
    action:
      - service: dsb_api.fetch_updates

Via Developer Tools

Go to Developer Tools → Services → search for dsb_api.fetch_updates → Call Service

---

📊 Sensor Details

Vertretungsplan Sensor

State: 2|a3f8c2d1 (change count + data hash – state only changes when actual data changes)

Attributes:

days:
  "2026-03-05":
    wochentag: donnerstag
    schedule:
      "1":
        fach: M
        raum: "110"
        lehrer: GEI
        uhrzeit: 08:00-08:45
        status: normal
        vertreter: null
        dsb_text: null
        dsb_art: null
      "3":
        fach: G
        raum: "008"
        lehrer: BRE
        uhrzeit: 09:50-10:35
        status: entfall
        vertreter: null
        dsb_text: "G (BRE) 3. Std. entfällt"
        dsb_art: Entfall
    changes:
      - stunde: "3"
        status: entfall
        fach: G
        text: "G (BRE) 3. Std. entfällt"
    change_count: 1
dates:
  - "2026-03-05"
schedule_raw:
  montag:
    "1": { fach: E1, raum: "108", lehrer: MUL, uhrzeit: "08:00-08:45" }
    # ...
config:
  meta: { schueler: MAX, klasse: 7B, ... }
  zeitraum: { start: "2026-02-04", ende: "2026-07-31" }
  ogts: { ... }
  lehrer_profil: [MUL, GEI, BRE, ...]
  emojis: { ... }
hashes:
  exams: "a1b2c3d4"
  termine: "e5f6g7h8"
  yaml: "i9j0k1l2"
klasse: "7B"
schueler: "MAX"
schedule_file: "MAX_Stundenplan.yaml"
last_updated: "2026-03-05T07:45:00"

Schulinfo Sensor

State: 2 (number of days with info)

Attributes:

tage:
  "2026-03-05":
    title: "Vertretungsplan Donnerstag 05.03.2026"
    nachrichten:
      - "Bitte beachten Sie die geänderten Pausenzeiten."
    stand: "05.03.2026 07:30"
    klassen_betroffen: ["5A", "6D", "7B", "10B"]
    total_eintraege: 12
dates:
  - "2026-03-05"
last_updated: "2026-03-05T07:45:00"

---

🔑 Hash Storage

The integration provides persistent hash storage for change detection in automations. Hashes are stored per child in .storage/dsb_[child]_hashes.json.

Set a Hash

service: dsb_api.set_hash
data:
  child_name: "MAX"
  hash_key: "exams"       # exams, termine, or yaml
  hash_value: "a1b2c3d4"

Read Hashes

Hashes are exposed in the Vertretungsplan sensor attributes:

{{ state_attr('sensor.dsb_max_7b_vertretungsplan', 'hashes').exams }}
{{ state_attr('sensor.dsb_max_7b_vertretungsplan', 'hashes').termine }}
{{ state_attr('sensor.dsb_max_7b_vertretungsplan', 'hashes').yaml }}

---

🏠 Dashboard Examples

Today's Changes Card (Markdown)

type: markdown
title: 📋 Vertretungsplan Heute
content: >
  {% set today = now().strftime('%Y-%m-%d') %}
  {% set days = state_attr('sensor.dsb_max_7b_vertretungsplan', 'days') %}
  {% set day = days.get(today, {}) %}
  {% set changes = day.get('changes', []) %}
  {% if changes | length > 0 %}
  {% for c in changes %}
  - **{{ c.stunde }}. Std.** {{ c.fach }}: {{ c.status }}
    {% if c.text %}– {{ c.text }}{% endif %}
  {% endfor %}
  {% else %}
  Keine Änderungen heute ✅
  {% endif %}

School Announcements Card (Markdown)

type: markdown
title: 📢 Schulnachrichten
content: >
  {% set info = state_attr('sensor.dsb_max_schulinfo', 'tage') %}
  {% for date, data in info.items() %}
  **{{ date }}** (Stand: {{ data.stand }})
  {% for msg in data.nachrichten %}
  - {{ msg }}
  {% endfor %}
  {% endfor %}

---

🐛 Troubleshooting

Problem	Solution
Login fails	Verify credentials at dsbmobile.de
No data after setup	Call dsb_api.fetch_updates manually
Schedule not loaded	Check file exists in /config/ and call dsb_api.reload_schedule
Wrong lessons shown	Review exclude rules in your YAML – check split class groups [1]
Sensor shows 0 changes	This is correct if there are no substitutions today
Entity ID wrong	Entity IDs are set at setup – delete & re-add integration

Enable Debug Logging

logger:
  default: info
  logs:
    custom_components.dsb_api: debug

---

📋 Changelog

v3.0.0

• 🧒 Child name & class in setup flow – determines entity IDs and default schedule filename
• 👨‍👩‍👧‍👦 Multi-child support – add integration multiple times with different children
• 🏷️ Smart sensor naming – sensor.dsb_[child]_[class]_vertretungsplan
• 🔑 Persistent hash storage – dsb_api.set_hash service for automation change detection
• 📝 Extended YAML support – ogts, termine_filter, emojis, zeitraum blocks
• 🔧 Config data in sensor – full YAML config exposed as config attribute
• 🧑‍🏫 Automatic teacher profile – lehrer_profil computed from timetable
• 🔀 Verlegung status – lesson relocations now detected separately
• 🐛 Fixed: OptionsFlow compatibility with HA 2024.x+

v2.2.4

• Stability improvements

v2.2.0

• Schedule YAML support
• Exclude rules for split classes
• Manual fetch via service

v1.0.0

• Initial release

---

📄 License

This project is licensed under the MIT License.

---

🙏 Credits

• Built for Home Assistant
• Data provided by DSB Mobile by heinekingmedia GmbH
• Inspired by ha-deutsche-ferien and Elternportal_API
